Three Axis Deep Hole Drilling Machine for Bottle Molds
Machine Details of Three Axis Deep Hole Drilling Machine for Bottle Molds
This machine is specially for drilling bottle molds, there are four spindles to drill at the same time.
Controlled by two servo motors.
Specification |
Parameter |
Remark |
||
Working capacity |
Drill hole diameter range |
Φ3~Φ15mm |
- |
|
Max. Drill depth |
1000mm |
- |
||
Max. Workpiece length |
1000mm |
- |
||
Max. Workpiece OD |
Φ254mm |
- |
||
Machine features |
X axis |
Travel |
300mm |
- |
Rapid move speed |
3000mm/min |
- |
||
Motor torque |
10Nm |
- |
||
Y axis |
Travel |
300mm |
- |
|
Rapid move speed |
2000mm/min |
- |
||
Motor torque |
22Nm |
- |
||
Z axis/ |
Infeeding speed range |
5~500mm/min |
Stepless |
|
Rapid move speed |
3000mm/min |
- |
||
Infeeding motor torque |
10Nm |
- |
||
Drill box |
Rotary speed range |
500~6000r/min |
Stepless |
|
Motor power |
5.5KW |
Servo spindle motor |
||
Coolant system |
Pressure range |
1~10MPa |
Adjustable |
|
Flow range |
6~200L/min |
Adjustable |
||
Filter accuracy |
20μm |
- |
||
Oil tank volume |
>1000L |
- |
||
